PRIME Titanium Fanless

Power. Performance. PRIME.

PRIME Titanium Fanless

The PRIME 600 Titanium Fanless utilizes the fanless technology, which eliminates the fan noise completely, ensuring truly quiet operation. The unit not only is rated to be 80PLUS Titanium efficient, but it also has the highest power output on the fanless power supply market at the moment. The power supply is ideal any situations that demand silence from the equipment. The high quality components inside and the innovative circuit design result in clean and stable power output. The fully modular cables allow for better cable management in the computer case.

  • ATX 12 V
  • Full Modular
  • 80 PLUS Titanium Certified
  • 12 Years Warranty
  • Dimensions: 170 mm (L) x 150 mm (W) x 86 mm (H)

wattage calculator Compare products where to buy

Overview

80 PLUS® Titanium

The PRIME Titanium Series achieves the highest level of 80 PLUS® Titanium certification on the market with its 94 % efficiency at 50 % system load.

Micro Tolerance Load Regulation

Seasonic’s latest design keeps the output voltage within a very tight range, achieving under 0.5 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems.

Seasonic Fanless Design

Cooling fans inside the power supply are replaced by passive cooling based on heat dissipation. Silent operation does not only provide a more pleasant working environment but it also results in less power consumption and lower utility bills.

feature summary

  • 80 PLUS® Titanium certified
  • Micro Tolerance Load Regulation (0.5 %)
  • True Fanless Design
  • Multi-GPU setup
  • Gold plated connectors
  • 12 years warranty

Specifications

SSR-600TL

Technical Specifications
80PLUS® Titanium
Cybenetics Efficiency Level ETA-A+ (View report)
Cybenetics Noise Level LAMBDA-A++ (View report)
Form Factor Intel ATX 12 V
Dimensions 170 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size N/A
Fan Control N/A
Fan Bearing N/A
Life Expectancy N/A
Cable Information Modularity Fully Modular
Cable type Webbed cables (MB, CPU, PCIe)
Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 12 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 8-4 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 20 A 20 A 50 A 0.3 A 2.5 A
100 W 600 W 3.6 W 12.5 W
Total continuous power 600 W

Cables

SSR-600TL

Cable typeConnector(s) per cableTotal Length (mm)Number(s) of cable(s) included
MB-610 MB (24/20 pins) 1 610 1
CPU-650 CPU (8/4 pins) 1 650 2
PCIe-750-2x PCIe (8/6 pins) 2 750 2
PCIe-750-1x PCIe (8/6 pins) 1 750 0
SATA-810-4x-90 SATA 4 810 1
SATA-800-4x-180 SATA 4 800 0
SATA-760-4x-90 SATA 4 760  0
SATA-700-2x-90 SATA 2 700 0
SATA-570-2x-180 SATA 2 570 0
SATA-470-2x-180 SATA 2 470 1
SATA-450-2x-180 SATA 2 450 0
Molex-690-3x Molex 3 690 1
Molex-470-2x Molex 2 470 1
Molex-to-SATA-3-3-300 Molex to SATA 3.3 Adapter 2 300 0
Molex-to-FDD-101 Molex to FDD Adapter 1 101  1

Specifications are subject to change without prior notice.
